OBEX CORTEX 0223FR Class A2 Breather Membrane is a UV-resistant external breather membrane for use in facades and other construction applications.  It is a water resistant, yet breathable membrane which facilitates the escape of moisture and the prevention of condensation within the external wall construction and can be applied to many surfaces such as sheathing board, concrete and insulation.

This specialist breather membrane has a watertightness rating of W1 and is therefore especially suited to demanding applications such as Modular construction where the highest levels of water resistance are required and also achieves a fire classification of A2-s1,d0 according to EN 13501-1.

The membrane is installed using the OBEX CORTEX 0825 Installation Kit which includes 2 rolls of 0824FR double-sided tape and 6 rolls of single sided 0823FR UV façade tape.

Typical Uses

Class A2 external breather membrane for use in facades and other construction applications
3rd Party Certified
12 Months Exposure
Class A
EI60 Fire Test Component
EI120 Fire Test Component
Breathable
W1 - EN 13859-2


Product Specs
Width
1200mm

Length
35m

Thickness
0.4mm

Colour
Silver Foil & White



Technical Specs
Harmonised Standard

EN 13859-2

Fire Classification | EN 13501-1

A2-s1,d0

Watertightness | EN 1928

W1

Sd Value | EN ISO 12572

0.08m

Tensile Strength | EN 12311-2

Longitudinal – 2968 N/50mm, Transversal 3253 N/50mm

3rd Party Approved

KIWA Approval – BAW-22-261-P-A-UK

12 Months UV Resistance

Data Sheets

Data Sheets

Decleration Of Performance

Installation Guide

Safety Data Sheet

Technical Data Sheet
