FD30 Letterplates for 44mm timber door profiles.

TS008 has come in to effect that sets the advanced security requirements of letterplates. The updated door standard PAS 24:2016, now requires a door fitted with a letterplate that is tested to and meets the requirements of TS008. As well as covering key fishing, TS008 also covers preventing being able to unlock the door through the letterplate, whilst also allowing postal items to pass freely through it.

Technical Specification

Application
Fire resisting, Secured by Design and/or PAS24
timber doorsets
Fixing
Bolted together
Performance
TS008 certified
Certifire approved
Smoke tested in accordance with BS EN 1634-3
Salt spray tested to BS EN 1670 - Class 5
20,000 cycles
Material
Aluminium (stainless steel Nanocoat option
available)
Door thickness (mm)
For 44mm timber door profiles
Size (mm)
305x75 (260x53 internal dimension)
Colours
Gold Anodised (GAA) / Polished Silver (PSL) / Satin Silver Anodised (SSA) / White (WHT)
Door types
Timber (TIN)
Fire rating
FD30 (30)


Data sheets

Manufacturer Data Sheet

Norseal Data Sheet

Certification CF 5723
