Technical Specification

Application
Fire resisting timber doorsets, 40-80mm thick
Fixing
Bolted together
Performance
Fire resistance in accordance with BS 476-22
Anti-snap flap with 180 degree opening
A4 aperture to BS 2911
Salt spray tested to BE EN 1670 - Class 5
20,000 cycle tested
Material
Plastic frame, high quality Zinc flaps
Size (mm)
310x68 (278x44 internal dimension)
Colours
Black frame - Polished Chrome (PC) / POLISHED GOLD (PG) / SILVER ANODISED (SA) / PAINTED SILVER (SIL) / SATIN SILVER (SS) / WHITE (WHT) / Other finishes on application

Data Sheets

Manufacturer Data Sheet

Fitting Guide

Certification CF 364
