Fischer Intumescent Graphite Mastic FiGM is a one part water based flexible acrylic emulsion containing a high pressure intumescent graphite which is used to seal service penetrations in both vertical and horizontal applications. Tested to both BS 476 & BS EN1366-3 /4 the fischer FiGM is also ETA approved and CE Marked for a wide range of applications such as, non metallic pipes, metallic and insulated pipes, MLC pipes, cables and cable bunches and can also used in combination with the fischer FCPS Coated Panel System.

Advantages

Low VOC
Excellent acoustic properties
Halogen and solvent free
Excellent slump characteristics

Applications

Metallic pipes: 6"" (159 mm)
Non-metallic pipes: 5"" (125 mm)
Cable bunches: 1"" (21 mm)
Insulated service: 6“ (159 mm)
Construction joints: 1“ (25 mm)
Mixed services

Building materials

Concrete
Masonry
Steel
Timber

Approval

ETA-20/1105
DoP No. FS-1006
1121-CPR-JA5047
UL-EU-00879-A1

Functionality

FiGM is a one-part water-based flexible acrylic emulsion containing a high pressure intumescent graphite, which is used to seal service penetrations in both vertical and horizontal applications.
It can expand up to 20 times its own volume and cures to form a resilient, flexible fire seal.

Datasheets

Safety data sheet for 508765 FiGM 310 ml
Safety data sheet for 558176 FiGM 600
Declaration of Performance
UL-Certificate
